8 Port 6Gb PCI-E 2.0 X8 RAID Controller Card O4267
8 Port 6Gb PCI-E 2.0 X8 RAID Controller Card O4267
1. Key Features : (1) Eight internal 6Gb/s SATA+SAS ports (2) Two Mini-SAS internal connectors (SFF-8087) (3) LSI SAS 2108 6Gb/s RAID-on-Chip –800MHzPowerPC
(4) 512MB 800MHz DDRII cache memory (5) Optional battery backup module (6) RAID Levels 0, 1, 5 and 6,RAID Spans 10, 50 and 60
2. Key Advantages : (1) 6Gb/s SAS for superior levels of RAID performance (2) PCI Express 2.0 provides faster signaling for highbandwidth applications (3) Support for 3Gb/s and 6Gb/s SATA and SAS hard drives (4) SafeStore Encryption Services formore secure data protection
3.Typical Applications: (1) Video-On-Demand,Video-Surveillance,Video Creation + Editing,Medical Imaging,High-Performance Computing (2) Digital Content Archive and VTL,Storage Appliance,File, Web, Database
LSIMegaRAID SAS LSI 9260-8i LSI00198 8 port 512MB cache SFF8087 6Gb RAID0.1.5.6 PCI-E 2.0 X8 Controller Card
1.Key Features
(1) Eight internal 6Gb/s SATA+SAS ports
(2) Two Mini-SAS internal connectors (SFF-8087)
(3) LSI SAS 2108 6Gb/s RAID-on-Chip –800MHzPowerPC
(4) 512MB 800MHz DDRII cache memory
(5) Optional battery backup module
（6) RAID Levels 0, 1, 5 and 6,RAID Spans 10, 50 and 60
2. Key Advantages
（1) 6Gb/s SAS for superior levels of RAID performance
（2) PCI Express 2.0 provides faster signaling for highbandwidth applications
（3) Support for 3Gb/s and 6Gb/s SATA and SAS hard drives
（4) SafeStore Encryption Services formore secure data protection
3.Typical Applications
（1) Video-On-Demand,Video-Surveillance,Video Creation + Editing,Medical Imaging,High-Performance Computing
（ 2) Digital Content Archive and VTL,Storage Appliance,File, Web, Database
